FIAT 2020 Emergency Start / FIAT Bypass Mini

FIAT 2020 Emergency Start / FIAT Bypass Mini

Product Overview:

• To use FIAT Bypass – Emergency Start Tool you just need to connect it to the OBD2 socket in the car.
• The tool bypasses the original immobiliser signal and allows you to start the car right after plugging it in.

Usage Requirements:

• Car has to be equipped with mechanical key.
• Car has to be equipped with original parts.
• The device will work only in case of a lost key.
• If the car is equipped with an SGW Module (some models starting from 2017 year), then you need to use 2018+ FCA Bypass Adapter in order to bypass Security Gateway Module

How to use:

1. Insert the device into OBD plug
2. (In some models produced from 2017 year, you have to use 2018+ FCA Security Gateway Module Bypass Adapter)
3. When you insert the product to the car, the red led will stay on (power).
4. After step 3, green led (code) will start blinking fast.
5. After turning the ignition ON, the green LED (code) will keep still. (succesfully completed)
6. Start the car.

—————————————————————————

• Note: If the green LED (code) keeps blinking fast after turning the ignition ON,
  take the key out, wait 30 seconds and turn the ignition ON again.
  Sometimes the procedure needs to be repeated again.



Supported cars (Europe)

Brand	Model	Engine	Year
Fiat	500	All	2007-2020
Fiat	500 Abarth	All	2008-2020
Fiat	500l	All	2007-2020
Fiat	500x	1.3 MultiJet	2014-2019
Fiat	Doblo	All	2011-2020
Fiat	Ducato	All	2010-2020
Fiat	Fiorino	All	2011-2020
Fiat	Grande Punto	All	2007-2020
Fiat	Grande Punto Abarth	All	2012-2020
Fiat	Panda	All	2012-2020
Fiat	Qubo	All	2008-2020
Fiat	Tipo	1.3 MultiJet	2014-2017
Alfa Romeo	Mito	All	2008-2020
Alfa Romeo	Giulietta	All	2012-2020
Citroen	Jumper	All	2012-2020
Ford	Ka	All	2008-2019
Iveco	All models	All	2010-2017
Jeep	Renegade	1.3 MultiJet	2017-2019
Lancia	Ypsilon	All	2012-2020
Peugeot	Boxer	All	2010-2020



Supported cars (South America)

Brand	Model	Engine	Year
Fiat	500	All	2014-2020
Fiat	Fiorino	All	2013-2021
Fiat	Idea	All	2010-2017
Fiat	Linea	1.4 T-Jet	2008-2018
Fiat	Palio	All	2011-2017
Fiat	Punto	All	2007-2011
Fiat	Punto EVO	All	2011-2017
Fiat	Toro	Diesel	2015-
Fiat	Qubo	Diesel	2008-2020
Ram	ProMaster Rapid	Diesel	2013-2018
Ram	V700 Rapid	Diesel	2012-2016
